產品描述
・Fully welded seams
Maintains optimal airtightness indise the cabinet to increase its nitrogen stability. Achieve effective control and save on nitrogen consumption expenses.
・Equal gas distribution
Unique & well thought out design. The air pipe is speciallt designed to evenly distribute the gas inside the cabinet.
・ANTI-SHOCK ACCESSORIES
In the event of a collision, the anti-collision disc prevents the body of the trolley from being hit directly. Protects the cart from damage.
・360 DEGREES ROTATION
Conductive axle: 360 degrees rotation, highly flexible, slient, shockproof, sturdy, and long lasting.
Accessory Equipment - Temperature and Humidity Controller
Generally, a floating ball type flowmeter is used to control nitrogen gas influx. Hsin Wei offers an advanced temperature and humidity control system that can be used with the nitrogen saving cabinet. It displays the temperature and humidity of the cabinet. It uses nitrogen to control the humidity of the cabinet to keep the humidity level stable, and help save on nitrogen consumption.
CH-200 Temperature and Humidity Controller
- The required humidity can be set according to the product category
- 24 hour monitoring of the humidity changes in the cabinet
- Can set the nitrogen flow to [stop] to save on nitrogen consumption
- Temperature and humidity correction function
- Open door warning: can set the delay time for an open door before starting the warning alert
| Temperature sensor accuracy | ±1.0 °C |
| Humidity sensor accuracy | ±3.0%RH |
| Temperature sensor resolution | 0.1 °C |
| Humidity sensor resolution | 0.1%RH |
| External dimensions | W220*D109*H136mm |
| Power supply | 110V / 220V 2A |
| *Power switch, temperature and humidity sensor, inlet and outlet pipe fittings (customizable diameter), stop intake (upon reaching set humidity) *Opening the door stops the nitrogen supply |
